Slant Bed Lathe High Accuracy Good Quality CNC Lathe Machine JX52D

产品价格

价格面议

付款和运输信息

付款方式 L/C, Swift转账
交易区 国内市场, 国际市场
运输信息EXW, FOB
了解运费

Slant Bed Lathe High Accuracy Good Quality CNC Lathe Machine JX52D

TAIZHOU JUXING INTELLIGENT EQUIPMENT CO.,LTD

产品详情

CNC turret lathe is widely used in various fields of the manufacturing industry, including the processing of automotive parts, mechanical parts, moulds, shafts, wheels, and various metal parts. It is suitable for the processing of large quantities, high precision, complex shapes, and various materials, which effectively improves the competitiveness and productivity of enterprises. High-precision machining: Engineered to meet the most stringent machining precision standards, our machine tool excels in providing extraordinary accuracy for tasks requiring ultra-fine cutting. It ensures impeccable internal and external precision, roundness, and coaxiality, thereby setting a new benchmark in high-precision engineering.

产品产地 中国
生产能力 100 套 / 每月
Brandjuxing cnc

规格

Model

JX52D HYDRAULIC SERVO TURRET MACHINE

Max.rotary diam over machine bed

500mm

Max.cut diameter of plate workpiece

280mm

Max.cut length of shaft workpiece

380mm

X/Z -axis max. stroke

225/400mm

Spindle runout

0.003mm

Spindle nose tape

A2-6

Spindle hole diameter

56mm

Drawn pipe hole diameter

45mm

Main motor power

7.5kw

Tailstock sleeve travel

65mm

Net dimension

2400*1680*1700mm

Net weight

3500kg

样品信息

最低订购量 1 set
样品价格 $20000 / set

装运港

中国

Shanghai Port
